| Direct-Acting 2/2-Way Valve |
The solenoid plunger directly opens or closes the main orifice. It does not require a minimum differential pressure. |
Two ports: one inlet and one outlet; normally closed or normally open. |
Clean air, water, low-viscosity liquids, inert gases, and selected oils when compatible materials are used. |
Often low to medium pressure; the actual rating depends on orifice size, construction, and seal material. |
Commonly about −10°C to 120°C; extended-temperature designs are available. |
Low-flow dosing, laboratory equipment, safety shutoff, compact pneumatic circuits, and applications with zero or very low pressure differential. |
Reliable at low pressure, simple construction, fast response, and flexible mounting orientation. |
Limited flow capacity at larger pressure drops; the coil may require comparatively high power for larger orifices. |
Verify minimum and maximum pressure, required flow rate, orifice diameter, leakage class, and normally open/closed state. |
| Pilot-Operated 2/2-Way Valve |
Solenoid force controls a pilot orifice; upstream pressure assists in lifting the diaphragm or piston. |
Two ports; normally closed and normally open versions are available. |
Water, air, gases, and clean low-viscosity liquids compatible with the diaphragm, piston, and body materials. |
Medium to high pressure and higher flow capacity than many direct-acting designs, subject to the product rating. |
Commonly about −10°C to 140°C, depending on elastomer, body, and media. |
Water treatment, compressed-air systems, irrigation, process utilities, and general industrial flow isolation. |
Large flow capacity, efficient coil sizing, and lower power consumption for many high-flow applications. |
Usually needs a minimum differential pressure; contaminated or viscous media can obstruct the pilot passage or diaphragm. |
Check minimum operating differential pressure, flow coefficient, media cleanliness, diaphragm compatibility, and pressure direction. |
| Semi-Direct-Lift Valve |
The plunger mechanically assists the diaphragm or seal while the pressure differential also contributes to opening and closing. |
Two ports; normally closed designs are common, with selected normally open options. |
Air, water, neutral gases, and moderately demanding liquid services when the internal materials are suitable. |
Low to medium pressure, often with a lower minimum differential pressure than a conventional pilot-operated valve. |
Commonly about −10°C to 130°C, depending on the seal and body material. |
Compact machinery, dispensing equipment, low-pressure process lines, and systems requiring moderate flow with dependable low-pressure switching. |
Balances direct-acting low-pressure performance with better flow capability and power efficiency. |
More mechanically complex than a direct-acting valve and may have narrower media and pressure limits than a full pilot-operated model. |
Compare low-pressure performance, response time, maximum differential pressure, flow coefficient, and allowable installation position. |
| 3/2-Way Solenoid Valve |
A single solenoid shifts one common port between two outlet paths, or alternately supplies and exhausts an actuator circuit. |
Three ports and two positions; normally closed, normally open, or universal configurations. |
Primarily clean, dry compressed air; some versions handle inert gases or selected fluids. |
Commonly used in pneumatic systems from vacuum or low pressure up to several bar; confirm the valve-specific rating. |
Often about 0°C to 60°C for standard pneumatic service, with wider ranges available. |
Single-acting cylinders, pneumatic grippers, diverter circuits, pilot control, and actuator exhaust or supply switching. |
Provides supply, exhaust, and actuator control in one compact valve. |
Not suitable when independent control of two actuator ports is required; exhaust flow and port orientation must be correctly configured. |
Confirm port function, flow direction, coil state, air quality, response time, and required actuator fail position. |
| 4/2- and 5/2-Way Solenoid Valve |
The spool shifts compressed air between supply, exhaust, and two actuator ports to reverse a double-acting actuator. |
Four or five ports with two positions; single-solenoid spring return or double-solenoid memory versions. |
Clean, dry, filtered compressed air; some designs support lubricated air if specified. |
Commonly approximately 2 to 10 bar for industrial pneumatic service, but the exact range is model-specific. |
Often about 0°C to 50°C for standard versions; cold-temperature and high-temperature options may be available. |
Double-acting cylinders, automation lines, assembly machines, material handling, and motion-control circuits. |
Fast directional switching, compact automation integration, and control of both extension and retraction. |
Requires clean air and correct exhaust management; spool valves may allow small internal leakage over time. |
Select port size, flow rate, switching time, coil voltage, manual override, mounting standard, and actuator fail-safe behavior. |
| Proportional Solenoid Flow Valve |
A variable electrical current changes plunger position or force, allowing approximate continuous flow adjustment rather than simple on/off control. |
Usually two-way; three-way proportional versions are also used for pressure or flow regulation. |
Clean gases and liquids with stable viscosity and compatible seals; filtration is generally important. |
Low to medium pressure in many compact designs; high-pressure versions require application-specific verification. |
Commonly about −10°C to 80°C, with the usable range affected by coil heating and media temperature. |
Dosing, burner-air control, medical and analytical equipment, test systems, and variable-speed pneumatic or hydraulic functions. |
Enables variable flow control, smoother adjustment, and reduced need for separate throttling components. |
More sensitive to pressure fluctuations, hysteresis, media contamination, and coil temperature than on/off valves; may require a current driver. |
Review flow-versus-current curves, repeatability, hysteresis, control signal, minimum controllable flow, and required filtration. |
| High-Temperature Solenoid Valve |
A direct-acting or pilot-operated mechanism uses heat-resistant body, insulation, coil, and sealing materials. |
Most commonly 2/2-way; 3/2-way and other configurations are available for specialized systems. |
Hot water, steam, heated air, thermal fluids, and selected process gases, subject to material compatibility. |
Varies significantly with temperature; steam and hot-fluid pressure ratings must be checked separately from cold-water ratings. |
Specialized versions may handle approximately 150°C to 200°C or more; the coil and seal rating must both be considered. |
Steam equipment, ovens, sterilizers, laundry systems, thermal processing, and heated-fluid control. |
Maintains automated shutoff or switching where standard elastomers and coils would degrade. |
Higher cost, greater heat transfer to the coil, increased seal wear, and possible need for a heat shield or remote installation. |
Confirm maximum media and ambient temperature, steam suitability, coil insulation class, seal material, heat dissipation, and pressure rating. |
| Cryogenic Solenoid Valve |
A specially designed plunger, body, extension tube, and seal arrangement isolates the coil from extremely cold media. |
Usually 2/2-way, with normally closed or normally open configurations. |
Liquid or gaseous nitrogen, oxygen, argon, carbon dioxide, and other cryogenic media when material and cleanliness requirements are met. |
Low to high pressure depending on construction; pressure changes during vaporization must be included in system design. |
Specialized designs may operate below −100°C and toward cryogenic temperatures near −196°C. |
Gas separation, laboratory systems, medical gas equipment, aerospace testing, and cryogenic storage or transfer. |
Designed for low-temperature performance, reduced heat leakage, and controlled cryogenic media isolation. |
Requires strict material compatibility, cleanliness, oxygen-service controls where applicable, and careful condensation or icing management. |
Specify minimum temperature, phase, Cv, allowable leakage, oxygen compatibility, insulation method, and pressure-relief requirements. |
| Explosion-Protected Solenoid Valve |
A standard valve function is combined with a certified enclosure, encapsulated coil, or intrinsically safe electrical interface. |
Commonly 2/2-way, 3/2-way, or 5/2-way depending on the process or pneumatic circuit. |
Process fluids, gases, or compressed air compatible with the selected valve and hazardous-area installation. |
Determined by the underlying valve design; the electrical certification does not define the fluid-pressure rating. |
Often about −20°C to 60°C for certified assemblies, with certification-specific limits. |
Chemical processing, oil and gas facilities, paint systems, fuel handling, and areas with flammable gas or dust. |
Reduces ignition risk when correctly selected, installed, wired, and maintained for the classified area. |
Larger physical size, higher cost, heat dissipation concerns, and strict certification and cable-gland requirements. |
Match the hazardous-area classification, gas or dust group, temperature class, protection method, ambient range, voltage, and certification region. |
| Chemical-Resistant Solenoid Valve |
Direct-acting or isolated-diaphragm construction keeps corrosive media away from vulnerable actuator components. |
Usually 2/2-way or 3/2-way; port materials may include engineered plastics or corrosion-resistant alloys. |
Acids, alkalis, deionized water, laboratory chemicals, and aggressive gases only when wetted materials are confirmed compatible. |
Generally low to medium pressure in compact plastic or isolated designs; chemical compatibility can limit the rating. |
Commonly about 0°C to 80°C, depending on body, diaphragm, and seal materials. |
Water treatment, semiconductor support equipment, laboratory analyzers, chemical dosing, and surface treatment. |
Improves service life and reduces contamination risk in corrosive or high-purity media systems. |
Material selection is highly application-specific; some plastics have limited temperature, pressure, or mechanical shock resistance. |
Check a compatibility chart for every wetted component, concentration, temperature, pressure, purity level, and permeation risk. |
